Wide scope of application: SDR transceiver core, SDR radio, HAM radio, test and measurement, radio astronomy, Wireless, Cellular, IoT, Media streaming, Command and control systems prototyping platforms This versatile and powerful transceiver features two independent USB 3.0 interfaces, enabling fully continuous Tx/Rx data streaming. With its Lime Microsystems LMS7002M RF Transceiver and Cypress CYUSB3014-BZXC USB 3.0 interface controllers, you can rest assured that your communication will be crystal-clear and reliable. Expand your working range to your desired level, choose your own transmission and reception modes, and change power and modulation in real-time. Create your own applications and algorithms for working with radio signals and achieve greater performance by updating software without purchasing additional equipment. Experience the incredible flexibility and performance of the EOTA SDR and free up space in your shack from unnecessary bulky equipment.

Where to Buy
Upgrade your radio game to the next level

Wide scope of application

Two independent USB 3.0 interfaces

True full duplex SDR transceiver

Fully continuous Tx/Rx data stream

Full duplex operation

SDRSharp compatible

RigExpertCare - 2 years of Warranty
  • Reliability is in the DNA of RigExpert Antenna and Cable analyzers.
  • RigExpertCare guarantees you two years of service or replacement of the device with a new one of your choice. Services are free.
  • Each RigExpert device goes through four phases of quality control before sending it to the user.
  • That’s why we are confident in the quality of our products.
  • But some integrated circuits may contain a hidden defect that shows up over time.
  • RigExpertCare takes this risk for you.
Where to service

RigExpert EOTA SDR

Continuous frequency range
  • 100 kHz – 3.8 GHz
IQ sample rate (bandwidth)
  • up to 61.44 MHz
Sample depth
  • 12 bits
Power Output (CW)
  • up to 10 dBm
Frequency stability
  • ±0.5 ppm
PCB dimensions
  • 100 mm x 64 mm
Outline dimensions
  • 114.9 mm x 64 mm x 16.9 mm
