Frequency range
0.1 to 1500 MHz
Frequency entry
1 kHz
Measurement for systems
25, 50, 75, 100, 150, 200, 300, 450 and 600 Ohm
SWR measurement range
1 to 10 in chart modes, 1 to 100 in numerical modes
R and X range
0…2000, -2000…2000
Display modes
Cable tools (stub tuner, length & velocity factor, cable loss and characteristic impedance measurement, LC meter, Multé), Optional open-short-load calibration, R, X chart, Smith chart, SWR at single or multiple frequencies, SWR chart, TDR chart (Time Domain Reflectometer), User OSL: 10 profiles available
RF output
Connector type: N, Output power: -10 dBm (at a load of 50 ohms), Output signal shape: square
Power
Max. 4 hours of continuous measurement, max. 2 days in standby mode when fully charged batteries are used, Three 1.2V Ni-MH batteries, type AA, Three 1.5V alkaline batteries, type AA, Three 3.7V LiPo batteries, 14200, When the analyzer is connected to a PC or a DC adapter with USB socket, it takes power from these sources
Interface
6x3 keys on the water-proof keypad, 800×480 color Blanview® display, Bluetooth Specification v.4.2, LE, Menus and help screens in English (by default), French, Italian, Japanese, Ukrainian, Portuguese, Spanish and German, USB connection to a personal computer
Operating temperature
0…40 °C (32…104 °F)
Weight
442 g (15.6 oz)
Dimensions
100 × 230 × 55 mm, (4 × 9 × 2 in)
Accessories inside the box
Soft case, battery charger, rechargeable batteries, USB cable, N to UHF adapter
GTIN-13
4820185420310
Note
Specifications are subject to change without notice, Мade in Ukraine
Frequency range
0.1 to 2000 MHz
Frequency entry
1 kHz
Measurement for systems
25, 50, 75, 100, 150, 200, 300, 450 and 600 Ohm
SWR measurement range
1 to 10 in chart modes, 1 to 100 in numerical modes
R and X range
0…2000, -2000…2000
Display modes
Cable tools (stub tuner, length & velocity factor, cable loss and characteristic impedance measurement, LC meter, Multé), Optional open-short-load calibration, R, X chart, Smith chart, SWR at single or multiple frequencies, SWR chart, TDR chart (Time Domain Reflectometer), User OSL: 10 profiles available
RF output
Connector type: N, Output power: -10 dBm (at a load of 50 ohms), Output signal shape: square
Power
Max. 4 hours of continuous measurement, max. 2 days in standby mode when fully charged batteries are used, Three 1.2V Ni-MH batteries, type AA, Three 1.5V alkaline batteries, type AA, Three 3.7V LiPo batteries, 14200, When the analyzer is connected to a PC or a DC adapter with USB socket, it takes power from these sources
Interface
6x3 keys on the water-proof keypad, 800×480 color Blanview® display, Bluetooth Specification v.4.2, LE, Menus and help screens in English (by default), French, Italian, Japanese, Ukrainian, Portuguese, Spanish and German, USB connection to a personal computer
Operating temperature
0…40 °C (32…104 °F)
Weight
442 g (15.6 oz)
Dimensions
100 × 230 × 55 mm, (4 × 9 × 2 in)
Accessories inside the box
Soft case, battery charger, rechargeable batteries, USB cable, N to UHF adapter
GTIN-13
4820185420310
Note
Specifications are subject to change without notice, Мade in Ukraine
Застосування
Frequency range
0.06 to 35 MHz
Frequency entry
1 kHz
Measurement for systems
25, 50, 75, 100 Ohm
SWR measurement range
1 to 10 in chart modes, 1 to 100 in numerical modes
R and X range
0…1000, -1000…1000 in chart modes, 0…10000, -10000…10000 in numerical modes
Display modes
R, X chart, 100 points, SWR chart, 100 points
RF output
Connector type: UHF (SO-239), Output power: +13 dBm (at 50 Ohm load), Output signal shape: square
Power
Max. 4 hours of continuous measurement, max. 2 days in standby mode when fully charged batteries are used, Two 1.2V Ni-MH batteries, type AA, When the analyzer is connected to a PC or a DC adapter with USB socket, it takes power from these sources
Interface
320×240 color TFT display, 6x3 keys on the water-proof keypad, USB connection to a personal computer
Accessories inside the box
Alkaline batteries, Soft case, USB cable, User’s manual
Dimensions
103 mm x 207 mm x 37 mm (4.1 in x 8.1 in x 1.4 in)
Operating temperature
0…40 °C (32…104 °F)
Weight
310 g (10.9 Oz) w/o batteries
GTIN-13
4820185420105
Note
Мade in Ukraine
Frequency range
0.06 to 55 MHz
Frequency entry
1 kHz
Measurement for systems
25, 50, 75, 100 Ohm
SWR measurement range
1 to 10 in chart modes, 1 to 100 in numerical modes
R and X range
0…1000, -1000…1000 in chart modes, 0…10000, -10000…10000 in numerical modes
Display modes
R, X chart, 100 points, Return loss chart, 100 points, Smith chart, 100 points, SWR at single or multiple frequencies, SWR chart, 100 points, SWR, return loss, R, X, Z, L, C at single frequency
RF output
Connector type: UHF (SO-239), Output power: +13 dBm (at 50 Ohm load), Output signal shape: square
Power
Max. 4 hours of continuous measurement, max. 2 days in standby mode when fully charged batteries are used, Two 1.2V Ni-MH batteries, type AA, Two 1.5V alkaline batteries, type AA, When the analyzer is connected to a PC or a DC adapter with USB socket, it takes power from these sources
Interface
320×240 color TFT display, 6x3 keys on the water-proof keypad, Menus and help screens in English (by default), Japanese, French, USB connection to a personal computer
Dimensions
103 mm x 207 mm x 37 mm (4.1 in x 8.1 in x 1.4 in)
Operating temperature
0…40 °C (32…104 °F)
Weight
310 g (10.9 Oz) w/o batteries
GTIN-13
4820185420099
Note
Specifications are subject to change without notice, Мade in Ukraine
Accessories inside the box
Alkaline batteries, RigExpert AA-55 ZOOM, Soft case, USB cable, User’s manual
Frequency range
0.1 to 650 MHz
Frequency entry
1 kHz
SWR measurement range
1 to 10 in chart modes, 1 to 100 in numerical modes
R and X range
0…2000, -2000…2000
Display modes
Optional open-short-load calibration, R, X chart, 20 to 500 points, Return loss chart, 20 to 500 points, Smith chart, 20 to 500 points, SWR at single or multiple frequencies, SWR chart, 20 to 500 points, TDR chart (Time Domain Reflectometer), Сable tools (StubTuner, Cable Length, Impedance, Loss measurements)
RF output
Connector type: N, Output power: -10 dBm (at a load of 50 ohms), Output signal shape: square
Power
Max. 4 hours of continuous measurement, max. 2 days in standby mode when fully charged batteries are used, Three 1.2V Ni-MH batteries, type AA, Three 1.5V alkaline batteries, type AA, When the analyzer is connected to a PC or a DC adapter with USB socket, it takes power from these sources
Interface
320×240 color TFT display, 6x3 keys on the water-proof keypad, Bluetooth Specification v.4.2, LE, Menus and help screens in English (by default), Japanese, Ukrainian, Polish, Spanish and German, USB connection to a personal computer
Operating temperature
0…40 °C (32…104 °F)
Weight
450 g (15.9 oz)
Dimensions
100 × 230 × 55 mm, (4 × 9 × 2 in)
Accessories inside the box
Soft case, battery charger, rechargeable batteries, USB cable, N to UHF adapter
GTIN-13
4820185420297
Note
Specifications are subject to change without notice, Мade in Ukraine
NCAGE Code
A37ZJ
Застосування
Frequency range
0.1 to 230 MHz
Frequency entry
1 kHz
Measurement for systems
12.5, 25, 28, 37, 50, 75, 100, 150, 200, 300, 450, 600 Ohm
SWR measurement range
1 to 10 in chart modes, 1 to 100 in numerical modes
R and X range
0… 10000, -10000… 10000
Display modes
Multé (a quick check of multiband antennas), SWR chart, 100 points, SWR, Return loss, R, X, Z, L, C, magnitude and phase angle at one frequency
RF output
Connector type: N, Output power: -10 dBm (at a load of 50 ohms), Output signal shape: square
Power
One lithium-ion battery 3.7 V type 18650, When the analyzer is connected to a PC or a DC adapter with USB socket, it takes power from these sources, Сharge time: 3 hours when using a charger
Interface
2 × 3 keys on the waterproof keyboard, Menus and help screens in English (by default), Japanese, Monochrome electronic paper display, 200 × 200, USB connection to a personal computer, v.4.2 BLE Single Mode, Class B
Dimensions
185 x 40 x 33 mm (7.3 x 1.6 x 1.3 inches)
Operating temperature
-15° … 40 ° C (5 … 104 ° F)
Weight
185 grams (6.5 Oz) with battery
Accessories inside the box
Lanyard, Quick start guide, USB cable
GTIN-13
4820185420259
Note
Specifications are subject to change without notice, Мade in Ukraine
Застосування
Frequency range
0.1 to 500 MHz
Frequency entry
1 kHz
Measurement for systems
12.5, 25, 28, 37, 50, 75, 100, 150, 200, 300, 450, 600 Ohm
SWR measurement range
1 to 10 in chart modes, 1 to 100 in numerical modes
R and X range
0… 10000, -10000… 10000
Display modes
HAM (a quick check of single band antenna), Multé (a quick check of multiband antennas), OSL calibration mode, SWR chart, 100 points, SWR, Return loss, R, X, Z, L, C, magnitude and phase angle at one frequency
RF output
Connector type: UHF (SO-239), Output power: -10 dBm (at a load of 50 ohms), Output signal shape: square
Power
One lithium-ion battery 3.7 V type 18650, When the analyzer is connected to a PC or a DC adapter with USB socket, it takes power from these sources, Сharge time: 3 hours when using a charger
Interface
2 × 3 keys on the waterproof keyboard, High contrast E Ink display, 200 × 200, Menus and help screens in English (by default), Japanese, v.4.2 BLE Single Mode, Class B
Operating temperature
-15° … 40 ° C (5 … 104 ° F)
Dimensions
185 x 40 x 33 mm (7.3 x 1.6 x 1.3 inches)
Weight
185 grams (6.5 Oz) with battery
Accessories inside the box
Lanyard, Quick start guide, USB cable
GTIN-13
4820185420358
Note
Specifications are subject to change without notice, Мade in Ukraine
Застосування
Frequency range
0.1 to 600 MHz
Frequency entry
1 kHz
Measurement for systems
12.5, 25, 28, 37, 50, 75, 100, 150, 200, 300, 450, 600 Ohm
SWR measurement range
1 to 10 in chart modes, 1 to 100 in numerical modes
R and X range
0… 10000, -10000… 10000
Display modes
Multé (a quick check of multiband antennas), SWR chart, 100 points, SWR, Return loss, R, X, Z, L, C, magnitude and phase angle at one frequency
RF output
Connector type: N, Output power: -10 dBm (at a load of 50 ohms), Output signal shape: square
Power
One lithium-ion battery 3.7 V type 18650, When the analyzer is connected to a PC or a DC adapter with USB socket, it takes power from these sources, Сharge time: 3 hours when using a charger
Interface
2 × 3 keys on the waterproof keyboard, 290×220 color TFT display, Menus and help screens in English (by default), Japanese, USB connection to a personal computer, v.4.2 BLE Single Mode, Class B
Operating temperature
-15° … 40 ° C (5 … 104 ° F)
Weight
185 grams (6.5 Oz) with battery
Dimensions
185 x 40 x 33 mm (7.3 x 1.6 x 1.3 inches)
GTIN-13
4820185420280
Accessories inside the box
Quick-start guide, Neck strap, USB cable, N-type to UHF adapter
Note
Specifications are subject to change without notice, Мade in Ukraine
Застосування
Frequency entry
1 kHz
Frequency range
0.1 to 1000 MHz
Measurement for systems
12.5, 25, 28, 37, 50, 75, 100, 150, 200, 300, 450, 600 Ohm
SWR measurement range
1 to 10 in chart modes, 1 to 100 in numerical modes
R and X range
0… 10000, -10000… 10000
Note
Specifications are subject to change without notice, Мade in Ukraine
Display modes
HAM (a quick check of single band antenna), Multé (a quick check of multiband antennas), OSL calibration mode, R, X chart, Return loss chart, Single (measure SWR, |Z|, R, X, C, L, RL, Mag&Phase), SWR chart, TDR (distance to fault), Сable tools (StubTuner, Cable Length, Impedance, Loss measurements)
RF output
Connector type: N, Output power: -10 dBm (at a load of 50 ohms), Output signal shape: square
Power
One lithium-ion battery 3.7 V type 18650, When the analyzer is connected to a PC or a DC adapter with USB socket, it takes power from these sources, Сharge time: 3 hours when using a charger
Interface
2 × 3 keys on the waterproof keyboard, 220x220 TFT, Menus and help screens in English (by default), Japanese, USB connection to a personal computer
Operating temperature
-20°- 55°C (-4°-131°F)
Weight
185 grams (6.5 Oz) with battery
Dimensions
185 x 40 x 33 mm (7.3 x 1.6 x 1.3 inches)
Accessories inside the box
Quick-start guide, Neck strap, USB cable, N-type to UHF adapter
GTIN-13
4820185420365
Застосування
Frequency range
0.1 to 1000 MHz
Frequency setting time
20 ms
Return values
Resistance, Reactance (signed), SWR, Return Loss
Output connector
SMA
Output power
-10 dBm
Power
USB or from 3V to 48V through Power port
Operating temperature
0…40 °C (32…104 °F)
Interface
USB, I2C, SPI, UART
Dimensions
30 x 40 x 4 mm (1 x 2 x 0.2 inches)
Weight
30 grams (3 Oz)
Warranty
1 year
Note
Specifications are subject to change without notice, Мade in Ukraine
GTIN-13
4820185420341
Застосування
Frequency range
0.1 to 1500 MHz
Frequency entry
1 kHz
Measurement for systems
25, 50, 75, 100, 150, 200, 300, 450 and 600 Ohm
SWR measurement range
1 to 10 in chart modes, 1 to 100 in numerical modes
R and X range
0…2000, -2000…2000
Display modes
Cable tools (stub tuner, length & velocity factor, cable loss and characteristic impedance measurement, LC meter, Multé), Optional open-short-load calibration, R, X chart, Smith chart, SWR at single or multiple frequencies, SWR chart, TDR chart (Time Domain Reflectometer), User OSL: 10 profiles available
RF output
Connector type: N, Output power: -10 dBm (at a load of 50 ohms), Output signal shape: square
Power
Max. 4 hours of continuous measurement, max. 2 days in standby mode when fully charged batteries are used, Three 1.2V Ni-MH batteries, type AA, Three 1.5V alkaline batteries, type AA, Three 3.7V LiPo batteries, 14200, When the analyzer is connected to a PC or a DC adapter with USB socket, it takes power from these sources
Interface
6x3 keys on the water-proof keypad, 800×480 color Blanview® display, Bluetooth Specification v.4.2, LE, Menus and help screens in English (by default), French, Italian, Japanese, Ukrainian, Portuguese, Spanish and German, USB connection to a personal computer
Operating temperature
0…40 °C (32…104 °F)
Weight
442 g (15.6 oz)
Dimensions
100 × 230 × 55 mm, (4 × 9 × 2 in)
Accessories inside the box
Soft case, battery charger, rechargeable batteries, USB cable, N to UHF adapter
GTIN-13
4820185420310
Note
Specifications are subject to change without notice, Мade in Ukraine
Frequency range
0.1 to 2000 MHz
Frequency entry
1 kHz
Measurement for systems
25, 50, 75, 100, 150, 200, 300, 450 and 600 Ohm
SWR measurement range
1 to 10 in chart modes, 1 to 100 in numerical modes
R and X range
0…2000, -2000…2000
Display modes
Cable tools (stub tuner, length & velocity factor, cable loss and characteristic impedance measurement, LC meter, Multé), Optional open-short-load calibration, R, X chart, Smith chart, SWR at single or multiple frequencies, SWR chart, TDR chart (Time Domain Reflectometer), User OSL: 10 profiles available
RF output
Connector type: N, Output power: -10 dBm (at a load of 50 ohms), Output signal shape: square
Power
Max. 4 hours of continuous measurement, max. 2 days in standby mode when fully charged batteries are used, Three 1.2V Ni-MH batteries, type AA, Three 1.5V alkaline batteries, type AA, Three 3.7V LiPo batteries, 14200, When the analyzer is connected to a PC or a DC adapter with USB socket, it takes power from these sources
Interface
6x3 keys on the water-proof keypad, 800×480 color Blanview® display, Bluetooth Specification v.4.2, LE, Menus and help screens in English (by default), French, Italian, Japanese, Ukrainian, Portuguese, Spanish and German, USB connection to a personal computer
Operating temperature
0…40 °C (32…104 °F)
Weight
442 g (15.6 oz)
Dimensions
100 × 230 × 55 mm, (4 × 9 × 2 in)
Accessories inside the box
Soft case, battery charger, rechargeable batteries, USB cable, N to UHF adapter
GTIN-13
4820185420310
Note
Specifications are subject to change without notice, Мade in Ukraine
Застосування
Frequency range
0.1 to 230 MHz
Frequency entry
1 kHz
Measurement for systems
25, 50, 75, 100, 150, 200, 300, 450 and 600 Ohm
SWR measurement range
1 to 10 in chart modes, 1 to 100 in numerical modes
R and X range
0…1000, -1000…1000 in chart modes, 0…10000, -10000…10000 in numerical modes
Display modes
Optional open-short-load calibration, R, X chart, 20 to 500 points, Return loss chart, 20 to 500 points, Smith chart, 20 to 500 points, SWR at single or multiple frequencies, SWR chart, 20 to 500 points, TDR chart (Time Domain Reflectometer), Сable tools (StubTuner, Cable Length, Impedance, Loss measurements)
RF output
Connector type: N, Output power: -10 dBm (at a load of 50 ohms), Output signal shape: square
Power
Four 1.2V Ni-MH batteries, type AAA, Four 1.5V alkaline batteries, type AAA, Max. 4 hours of continuous measurement, max. 2 days in standby mode when fully charged batteries are used, When the analyzer is connected to a PC or a DC adapter with USB socket, it takes power from these sources
Interface
290×220 color TFT display, 6x3 keys on the water-proof keypad, Bluetooth Specification v.4.2, LE, Menus and help screens in English (by default), Japanese, USB connection to a personal computer
Dimensions
82 x 182 x 32 mm (3.2 x 7.2 x 1.3 in)
Operating temperature
0…40 °C (32…104 °F)
Weight
236 g (8.32 oz)
Accessories inside the box
Alkaline batteries, N Male SO-239 Female adaptor, Soft case, USB cable, User’s manual
GTIN-13
4820185420082
Note
Specifications are subject to change without notice, Мade in Ukraine
Frequency range
0.1 to 650 MHz
Frequency entry
1 kHz
SWR measurement range
1 to 10 in chart modes, 1 to 100 in numerical modes
R and X range
0…2000, -2000…2000
Display modes
Optional open-short-load calibration, R, X chart, 20 to 500 points, Return loss chart, 20 to 500 points, Smith chart, 20 to 500 points, SWR at single or multiple frequencies, SWR chart, 20 to 500 points, TDR chart (Time Domain Reflectometer), Сable tools (StubTuner, Cable Length, Impedance, Loss measurements)
RF output
Connector type: N, Output power: -10 dBm (at a load of 50 ohms), Output signal shape: square
Power
Max. 4 hours of continuous measurement, max. 2 days in standby mode when fully charged batteries are used, Three 1.2V Ni-MH batteries, type AA, Three 1.5V alkaline batteries, type AA, When the analyzer is connected to a PC or a DC adapter with USB socket, it takes power from these sources
Interface
320×240 color TFT display, 6x3 keys on the water-proof keypad, Bluetooth Specification v.4.2, LE, Menus and help screens in English (by default), Japanese, Ukrainian, Polish, Spanish and German, USB connection to a personal computer
Operating temperature
0…40 °C (32…104 °F)
Weight
450 g (15.9 oz)
Dimensions
100 × 230 × 55 mm, (4 × 9 × 2 in)
Accessories inside the box
Soft case, battery charger, rechargeable batteries, USB cable, N to UHF adapter
GTIN-13
4820185420297
Note
Specifications are subject to change without notice, Мade in Ukraine
NCAGE Code
A37ZJ
Застосування
Frequency range
0.1 to 230 MHz
Frequency entry
1 kHz
Measurement for systems
12.5, 25, 28, 37, 50, 75, 100, 150, 200, 300, 450, 600 Ohm
SWR measurement range
1 to 10 in chart modes, 1 to 100 in numerical modes
R and X range
0… 10000, -10000… 10000
Display modes
Multé (a quick check of multiband antennas), SWR chart, 100 points, SWR, Return loss, R, X, Z, L, C, magnitude and phase angle at one frequency
RF output
Connector type: N, Output power: -10 dBm (at a load of 50 ohms), Output signal shape: square
Power
One lithium-ion battery 3.7 V type 18650, When the analyzer is connected to a PC or a DC adapter with USB socket, it takes power from these sources, Сharge time: 3 hours when using a charger
Interface
2 × 3 keys on the waterproof keyboard, Menus and help screens in English (by default), Japanese, Monochrome electronic paper display, 200 × 200, USB connection to a personal computer, v.4.2 BLE Single Mode, Class B
Dimensions
185 x 40 x 33 mm (7.3 x 1.6 x 1.3 inches)
Operating temperature
-15° … 40 ° C (5 … 104 ° F)
Weight
185 grams (6.5 Oz) with battery
Accessories inside the box
Lanyard, Quick start guide, USB cable
GTIN-13
4820185420259
Note
Specifications are subject to change without notice, Мade in Ukraine
Застосування
Frequency range
0.1 to 500 MHz
Frequency entry
1 kHz
Measurement for systems
12.5, 25, 28, 37, 50, 75, 100, 150, 200, 300, 450, 600 Ohm
SWR measurement range
1 to 10 in chart modes, 1 to 100 in numerical modes
R and X range
0… 10000, -10000… 10000
Display modes
HAM (a quick check of single band antenna), Multé (a quick check of multiband antennas), OSL calibration mode, SWR chart, 100 points, SWR, Return loss, R, X, Z, L, C, magnitude and phase angle at one frequency
RF output
Connector type: UHF (SO-239), Output power: -10 dBm (at a load of 50 ohms), Output signal shape: square
Power
One lithium-ion battery 3.7 V type 18650, When the analyzer is connected to a PC or a DC adapter with USB socket, it takes power from these sources, Сharge time: 3 hours when using a charger
Interface
2 × 3 keys on the waterproof keyboard, High contrast E Ink display, 200 × 200, Menus and help screens in English (by default), Japanese, v.4.2 BLE Single Mode, Class B
Operating temperature
-15° … 40 ° C (5 … 104 ° F)
Dimensions
185 x 40 x 33 mm (7.3 x 1.6 x 1.3 inches)
Weight
185 grams (6.5 Oz) with battery
Accessories inside the box
Lanyard, Quick start guide, USB cable
GTIN-13
4820185420358
Note
Specifications are subject to change without notice, Мade in Ukraine
Застосування
Frequency range
0.1 to 600 MHz
Frequency entry
1 kHz
Measurement for systems
12.5, 25, 28, 37, 50, 75, 100, 150, 200, 300, 450, 600 Ohm
SWR measurement range
1 to 10 in chart modes, 1 to 100 in numerical modes
R and X range
0… 10000, -10000… 10000
Display modes
Multé (a quick check of multiband antennas), SWR chart, 100 points, SWR, Return loss, R, X, Z, L, C, magnitude and phase angle at one frequency
RF output
Connector type: N, Output power: -10 dBm (at a load of 50 ohms), Output signal shape: square
Power
One lithium-ion battery 3.7 V type 18650, When the analyzer is connected to a PC or a DC adapter with USB socket, it takes power from these sources, Сharge time: 3 hours when using a charger
Interface
2 × 3 keys on the waterproof keyboard, 290×220 color TFT display, Menus and help screens in English (by default), Japanese, USB connection to a personal computer, v.4.2 BLE Single Mode, Class B
Operating temperature
-15° … 40 ° C (5 … 104 ° F)
Weight
185 grams (6.5 Oz) with battery
Dimensions
185 x 40 x 33 mm (7.3 x 1.6 x 1.3 inches)
GTIN-13
4820185420280
Accessories inside the box
Quick-start guide, Neck strap, USB cable, N-type to UHF adapter
Note
Specifications are subject to change without notice, Мade in Ukraine
Застосування
Frequency entry
1 kHz
Frequency range
0.1 to 1000 MHz
Measurement for systems
12.5, 25, 28, 37, 50, 75, 100, 150, 200, 300, 450, 600 Ohm
SWR measurement range
1 to 10 in chart modes, 1 to 100 in numerical modes
R and X range
0… 10000, -10000… 10000
Note
Specifications are subject to change without notice, Мade in Ukraine
Display modes
HAM (a quick check of single band antenna), Multé (a quick check of multiband antennas), OSL calibration mode, R, X chart, Return loss chart, Single (measure SWR, |Z|, R, X, C, L, RL, Mag&Phase), SWR chart, TDR (distance to fault), Сable tools (StubTuner, Cable Length, Impedance, Loss measurements)
RF output
Connector type: N, Output power: -10 dBm (at a load of 50 ohms), Output signal shape: square
Power
One lithium-ion battery 3.7 V type 18650, When the analyzer is connected to a PC or a DC adapter with USB socket, it takes power from these sources, Сharge time: 3 hours when using a charger
Interface
2 × 3 keys on the waterproof keyboard, 220x220 TFT, Menus and help screens in English (by default), Japanese, USB connection to a personal computer
Operating temperature
-20°- 55°C (-4°-131°F)
Weight
185 grams (6.5 Oz) with battery
Dimensions
185 x 40 x 33 mm (7.3 x 1.6 x 1.3 inches)
Accessories inside the box
Quick-start guide, Neck strap, USB cable, N-type to UHF adapter
GTIN-13
4820185420365
Застосування
Frequency range
0.1 to 1000 MHz
Frequency setting time
20 ms
Return values
Resistance, Reactance (signed), SWR, Return Loss
Output connector
SMA
Output power
-10 dBm
Power
USB or from 3V to 48V through Power port
Operating temperature
0…40 °C (32…104 °F)
Interface
USB, I2C, SPI, UART
Dimensions
30 x 40 x 4 mm (1 x 2 x 0.2 inches)
Weight
30 grams (3 Oz)
Warranty
1 year
Note
Specifications are subject to change without notice, Мade in Ukraine
GTIN-13
4820185420341
Застосування
Frequency range
0.1 to 3000 MHz
Frequency entry
1 kHz
SWR measurement range
1 to 10 in chart modes, 1 to 100 in numerical modes
R and X range
0…2000, -2000…2000
Display modes
Cable tools (stub tuner, length & velocity factor, cable loss and characteristic impedance measurement, LC meter, Multé), Optional open-short-load calibration, R, X chart, Return loss chart, Smith chart, SWR at single or multiple frequencies, SWR chart, SWR, return loss, R, X, Z, L, C at single frequency, TDR chart (Time Domain Reflectometer), User OSL: 10 profiles available
RF output
Connector type: N, Output power: -10 dBm (at a load of 50 ohms), Output signal shape: square
Power
Max. 5 hours of continuous measurement, max. 2 days in standby mode when fully charged batteries are used, Three 1.2V Ni-MH batteries, type AA, Three 3.7V LiPo batteries, 14200, When the analyzer is connected to a PC or a DC adapter with USB socket, it takes power from these sources
Interface
6x3 keys on the water-proof keypad, 800×480 color Blanview® display, Bluetooth Specification v.4.2, LE, Menus and help screens in English (by default), French, Italian, Japanese, Ukrainian, Portuguese, Spanish and German, USB connection to a personal computer
Operating temperature
0…40 °C (32…104 °F)
Weight
442 g (15.6 oz)
Dimensions
100 × 230 × 55 mm, (4 × 9 × 2 in)
Note
Specifications are subject to change without notice, Мade in Ukraine
GTIN-13
4820185420372
Застосування
Frequency range
0.1 to 1500 MHz
Frequency entry
1 kHz
Measurement for systems
25, 50, 75, 100, 150, 200, 300, 450 and 600 Ohm
SWR measurement range
1 to 10 in chart modes, 1 to 100 in numerical modes
R and X range
0…2000, -2000…2000
Display modes
Cable tools (stub tuner, length & velocity factor, cable loss and characteristic impedance measurement, LC meter, Multé), Optional open-short-load calibration, R, X chart, Smith chart, SWR at single or multiple frequencies, SWR chart, TDR chart (Time Domain Reflectometer), User OSL: 10 profiles available
RF output
Connector type: N, Output power: -10 dBm (at a load of 50 ohms), Output signal shape: square
Power
Max. 4 hours of continuous measurement, max. 2 days in standby mode when fully charged batteries are used, Three 1.2V Ni-MH batteries, type AA, Three 1.5V alkaline batteries, type AA, Three 3.7V LiPo batteries, 14200, When the analyzer is connected to a PC or a DC adapter with USB socket, it takes power from these sources
Interface
6x3 keys on the water-proof keypad, 800×480 color Blanview® display, Bluetooth Specification v.4.2, LE, Menus and help screens in English (by default), French, Italian, Japanese, Ukrainian, Portuguese, Spanish and German, USB connection to a personal computer
Operating temperature
0…40 °C (32…104 °F)
Weight
442 g (15.6 oz)
Dimensions
100 × 230 × 55 mm, (4 × 9 × 2 in)
Accessories inside the box
Soft case, battery charger, rechargeable batteries, USB cable, N to UHF adapter
GTIN-13
4820185420310
Note
Specifications are subject to change without notice, Мade in Ukraine
Frequency range
0.1 to 2000 MHz
Frequency entry
1 kHz
Measurement for systems
25, 50, 75, 100, 150, 200, 300, 450 and 600 Ohm
SWR measurement range
1 to 10 in chart modes, 1 to 100 in numerical modes
R and X range
0…2000, -2000…2000
Display modes
Cable tools (stub tuner, length & velocity factor, cable loss and characteristic impedance measurement, LC meter, Multé), Optional open-short-load calibration, R, X chart, Smith chart, SWR at single or multiple frequencies, SWR chart, TDR chart (Time Domain Reflectometer), User OSL: 10 profiles available
RF output
Connector type: N, Output power: -10 dBm (at a load of 50 ohms), Output signal shape: square
Power
Max. 4 hours of continuous measurement, max. 2 days in standby mode when fully charged batteries are used, Three 1.2V Ni-MH batteries, type AA, Three 1.5V alkaline batteries, type AA, Three 3.7V LiPo batteries, 14200, When the analyzer is connected to a PC or a DC adapter with USB socket, it takes power from these sources
Interface
6x3 keys on the water-proof keypad, 800×480 color Blanview® display, Bluetooth Specification v.4.2, LE, Menus and help screens in English (by default), French, Italian, Japanese, Ukrainian, Portuguese, Spanish and German, USB connection to a personal computer
Operating temperature
0…40 °C (32…104 °F)
Weight
442 g (15.6 oz)
Dimensions
100 × 230 × 55 mm, (4 × 9 × 2 in)
Accessories inside the box
Soft case, battery charger, rechargeable batteries, USB cable, N to UHF adapter
GTIN-13
4820185420310
Note
Specifications are subject to change without notice, Мade in Ukraine
Застосування
Frequency range
0.1 to 650 MHz
Frequency entry
1 kHz
SWR measurement range
1 to 10 in chart modes, 1 to 100 in numerical modes
R and X range
0…2000, -2000…2000
Display modes
Optional open-short-load calibration, R, X chart, 20 to 500 points, Return loss chart, 20 to 500 points, Smith chart, 20 to 500 points, SWR at single or multiple frequencies, SWR chart, 20 to 500 points, TDR chart (Time Domain Reflectometer), Сable tools (StubTuner, Cable Length, Impedance, Loss measurements)
RF output
Connector type: N, Output power: -10 dBm (at a load of 50 ohms), Output signal shape: square
Power
Max. 4 hours of continuous measurement, max. 2 days in standby mode when fully charged batteries are used, Three 1.2V Ni-MH batteries, type AA, Three 1.5V alkaline batteries, type AA, When the analyzer is connected to a PC or a DC adapter with USB socket, it takes power from these sources
Interface
320×240 color TFT display, 6x3 keys on the water-proof keypad, Bluetooth Specification v.4.2, LE, Menus and help screens in English (by default), Japanese, Ukrainian, Polish, Spanish and German, USB connection to a personal computer
Operating temperature
0…40 °C (32…104 °F)
Weight
450 g (15.9 oz)
Dimensions
100 × 230 × 55 mm, (4 × 9 × 2 in)
Accessories inside the box
Soft case, battery charger, rechargeable batteries, USB cable, N to UHF adapter
GTIN-13
4820185420297
Note
Specifications are subject to change without notice, Мade in Ukraine
NCAGE Code
A37ZJ
Застосування
Frequency range
0.1 to 500 MHz
Frequency entry
1 kHz
Measurement for systems
12.5, 25, 28, 37, 50, 75, 100, 150, 200, 300, 450, 600 Ohm
SWR measurement range
1 to 10 in chart modes, 1 to 100 in numerical modes
R and X range
0… 10000, -10000… 10000
Display modes
HAM (a quick check of single band antenna), Multé (a quick check of multiband antennas), OSL calibration mode, SWR chart, 100 points, SWR, Return loss, R, X, Z, L, C, magnitude and phase angle at one frequency
RF output
Connector type: UHF (SO-239), Output power: -10 dBm (at a load of 50 ohms), Output signal shape: square
Power
One lithium-ion battery 3.7 V type 18650, When the analyzer is connected to a PC or a DC adapter with USB socket, it takes power from these sources, Сharge time: 3 hours when using a charger
Interface
2 × 3 keys on the waterproof keyboard, High contrast E Ink display, 200 × 200, Menus and help screens in English (by default), Japanese, v.4.2 BLE Single Mode, Class B
Operating temperature
-15° … 40 ° C (5 … 104 ° F)
Dimensions
185 x 40 x 33 mm (7.3 x 1.6 x 1.3 inches)
Weight
185 grams (6.5 Oz) with battery
Accessories inside the box
Lanyard, Quick start guide, USB cable
GTIN-13
4820185420358
Note
Specifications are subject to change without notice, Мade in Ukraine
Застосування
Frequency range
0.1 to 600 MHz
Frequency entry
1 kHz
Measurement for systems
12.5, 25, 28, 37, 50, 75, 100, 150, 200, 300, 450, 600 Ohm
SWR measurement range
1 to 10 in chart modes, 1 to 100 in numerical modes
R and X range
0… 10000, -10000… 10000
Display modes
Multé (a quick check of multiband antennas), SWR chart, 100 points, SWR, Return loss, R, X, Z, L, C, magnitude and phase angle at one frequency
RF output
Connector type: N, Output power: -10 dBm (at a load of 50 ohms), Output signal shape: square
Power
One lithium-ion battery 3.7 V type 18650, When the analyzer is connected to a PC or a DC adapter with USB socket, it takes power from these sources, Сharge time: 3 hours when using a charger
Interface
2 × 3 keys on the waterproof keyboard, 290×220 color TFT display, Menus and help screens in English (by default), Japanese, USB connection to a personal computer, v.4.2 BLE Single Mode, Class B
Operating temperature
-15° … 40 ° C (5 … 104 ° F)
Weight
185 grams (6.5 Oz) with battery
Dimensions
185 x 40 x 33 mm (7.3 x 1.6 x 1.3 inches)
GTIN-13
4820185420280
Accessories inside the box
Quick-start guide, Neck strap, USB cable, N-type to UHF adapter
Note
Specifications are subject to change without notice, Мade in Ukraine
Застосування
Frequency entry
1 kHz
Frequency range
0.1 to 1000 MHz
Measurement for systems
12.5, 25, 28, 37, 50, 75, 100, 150, 200, 300, 450, 600 Ohm
SWR measurement range
1 to 10 in chart modes, 1 to 100 in numerical modes
R and X range
0… 10000, -10000… 10000
Note
Specifications are subject to change without notice, Мade in Ukraine
Display modes
HAM (a quick check of single band antenna), Multé (a quick check of multiband antennas), OSL calibration mode, R, X chart, Return loss chart, Single (measure SWR, |Z|, R, X, C, L, RL, Mag&Phase), SWR chart, TDR (distance to fault), Сable tools (StubTuner, Cable Length, Impedance, Loss measurements)
RF output
Connector type: N, Output power: -10 dBm (at a load of 50 ohms), Output signal shape: square
Power
One lithium-ion battery 3.7 V type 18650, When the analyzer is connected to a PC or a DC adapter with USB socket, it takes power from these sources, Сharge time: 3 hours when using a charger
Interface
2 × 3 keys on the waterproof keyboard, 220x220 TFT, Menus and help screens in English (by default), Japanese, USB connection to a personal computer
Operating temperature
-20°- 55°C (-4°-131°F)
Weight
185 grams (6.5 Oz) with battery
Dimensions
185 x 40 x 33 mm (7.3 x 1.6 x 1.3 inches)
Accessories inside the box
Quick-start guide, Neck strap, USB cable, N-type to UHF adapter
GTIN-13
4820185420365
Застосування
Frequency range
0.1 to 1000 MHz
Frequency setting time
20 ms
Return values
Resistance, Reactance (signed), SWR, Return Loss
Output connector
SMA
Output power
-10 dBm
Power
USB or from 3V to 48V through Power port
Operating temperature
0…40 °C (32…104 °F)
Interface
USB, I2C, SPI, UART
Dimensions
30 x 40 x 4 mm (1 x 2 x 0.2 inches)
Weight
30 grams (3 Oz)
Warranty
1 year
Note
Specifications are subject to change without notice, Мade in Ukraine
GTIN-13
4820185420341
Застосування
Frequency range
50 MHz - 6 GHz (coverage 25 - 6025 MHz)
Operation modes
double conversion heterodyne for VHF/UHF range, two-channel direct sampling for HF range
ADC resolution
14 bits
Frequency stability
±0.5 ppm
Blocking Dynamic Range
82 dB UHF/VHF, 86 dB in HF
Selectivity
-110 dBm combined selectivity
IQ Image rejection
52 dB (software)
Maximum RF input
+10 dBm
Power source
USB Plug, 3.8 - 5.5 V nominal
Current consumption
450 mA in idle state, 670 mA in direct sampling mode, 850 mA in full-band operating mode
Clock source
external, selectable within API, internal
External clock input
10 MHz, high impedance
Clock output
10 MHz, 5Ohm, 3.0 V p2p, permanent
Operating temperature
0..+60°C
PCB type
6-layer impedance controlled, ENIG finished
PCB dimensions
110 mm x 60 mm
Outline dimensions
130 mm x 60 mm x 16 mm
Weight
143 g
Maximum current
3.5А
Compatibility
USB 2.0, 3.0, 3.1 and 3.2 data transfer standards
Length
100 cm
Бренд
Застосування
Maximum current
3.5А
Compatibility
USB 2.0, 3.0, 3.1 and 3.2 data transfer standards
Length
100 cm
Бренд
Застосування
Number of interfaces
3
Interface type
N male 50 Ohm
Frequency range
DC to 2.5 GHz
Power rating
250mW
Return loss
-22 dB @ 3 GHz, -31 dB @ DC to 1.5 GHz
DC-resistance Lad
50 Ohm
Operating temperature range
-15°C to +55°C
Storage temperature range
-40°C to +85°C
Weight
110g
Dimensions
49 mm x 84.6 mm x 25 mm
GTIN-13
4820185420433
Number of interfaces
3
Interface type
N male 50 Ohm
Frequency range
DC to 2.5 GHz
Power rating
250mW
Return loss
-22 dB @ 3 GHz, -31 dB @ DC to 1.5 GHz
DC-resistance Lad
50 Ohm
Operating temperature range
-15°C to +55°C
Storage temperature range
-40°C to +85°C
Weight
110g
Dimensions
49 mm x 84.6 mm x 25 mm
GTIN-13
4820185420433
Frequency range
0.06 to 30 MHz
Frequency entry
1 Hz
Measurement for systems
25, 50, 75, 100 Ohm
Housing
none, PCB only – available as a kit
Display
4 LEDs
Communication interface
UART, 38400 baud
SWR measurement range
1 to 100
R and X range
0… 10000, -10000… 10000
RF output
Connector type: SMA, Output power: +13 dBm (at 50 Ohm load), Output signal shape: square, 0.06 to 30 MHz
Power
Current consumption (max) 150 mA, Supply: external 5V
General data
Dimensions (W x H x D), PCB only w/o connectors: 55 mm x 69 mm x 5 mm (2.1 in x 2.7 in x 0.2 in), Operating temperature: 0…40 °C (32…104 °F), Weight w/o connectors: 65 g (2.29 Oz)
Note
Specifications are subject to change without notice, Мade in Ukraine
Frequency range
0.1 to 1000 MHz
Frequency setting time
20 ms
Return values
Resistance, Reactance (signed), SWR, Return Loss
Output connector
SMA
Output power
-10 dBm
Power
USB or from 3V to 48V through Power port
Operating temperature
0…40 °C (32…104 °F)
Interface
USB, I2C, SPI, UART
Dimensions
30 x 40 x 4 mm (1 x 2 x 0.2 inches)
Weight
30 grams (3 Oz)
Warranty
1 year
Note
Specifications are subject to change without notice, Мade in Ukraine
GTIN-13
4820185420341
Застосування
Бренд
PLL synthesized outputs
4
Output frequency range
0.16 to 200/350/710 MHz (depending on a PLL type)
Frequency setting
With 1 Hz steps (or very fine tuning with 1 ppt steps)
Auxiliary output
10 MHz
Frequency stability
0.001 ppm or better
Signal levels
3.3V CMOS logic
Output connector
BNC
GNSS antenna type
External, active, 3.3V
GNSS constellations
GPS, Galileo
Dimensions
100mm x 100mm x 25mm (PCB), 105mm x 105mm x 35mm (enclosure)
Accessories inside the box
12V power adapter (EU or US), GPS active antenna, USB cable, User’s manual
Note
Made in EU, Specifications are subject to change without notice
GTIN-13
4820185420440
Бренд
Застосування
Number of measuring channels
3
Measuring range
Current – 10μA to 1А (1 channel), Voltage – 0V to 5V (2 channels)
Sample rate
10 hZ…10 kHz (10 kHz one channel only)
Measuring results displaying
Average values in digital format, Easy navigation using horizontal and vertical zooming, Instant values graph, Saving data to a log
Power supply
Additional built-in Li-ion battery to be used when current consumption is over 500 mA, PC USB port
Interface
3 languages support (EN, UA, RU), Application software “REAMP Logger”, Operation system Windows 7, Windows 8, Windows 10, USB connection to a PC (USB 2.0, USB 3.0)
Dimensions
67 mm x 57 mm x 27 mm
Operating temperature
0…40 °C (32…104 °F)
Weight
100 g
Warranty
1 year
GTIN-13
4820185420334
Note
Specifications are subject to change without notice, Мade in Ukraine
Maximum current
3.5А
Compatibility
USB 2.0, 3.0, 3.1 and 3.2 data transfer standards
Length
100 cm
Бренд
Застосування
Maximum current
3.5А
Compatibility
USB 2.0, 3.0, 3.1 and 3.2 data transfer standards
Length
100 cm
Бренд
Застосування
Бренд
Бренд
Frequency range
0.1 to 1400 MHz
Frequency entry
1 kHz resolution
SWR measurement range
1 to 10 in graph mode, 1 to 100 in numerical modes
R and X range
0…1000, -1000…1000 in graph mode, 0…10000, -10000…10000 in numerical modes
Display modes
R, X graph, 80 points, Smith (or polar) chart, 80 points, SWR at single or multiple frequencies, SWR graph, 80 points, SWR, return loss, R, X, Z, L, C at single frequency, TDR (Time Domain Reflectometer) graph
RF output
Connector type: N, Output power: -10 dBm (at a load of 50 ohms), Output signal shape: square, 0.1 to 200 MHz. For higher frequencies, harmonics of the main signal are used.
Power
Max. 3 hours of continuous measurement, max. 2 days in stand-by mode when fully charged batteries are used, Three 1.2V, 1800…3000 mAh, Ni-MH batteries, type AA, When the analyzer is connected to a PC or a DC adapter with USB socket, it takes power from these sources
Interface
320×240 color TFT display, 6x3 keys on the water-proof keypad, Multilingual menus and help screens, USB connection to a personal computer
Dimensions
230x100x55 mm (9x4x2”)
Operating temperature
0…40 °C (32…104 °F)
Weight
650g (23 Oz)
GTIN-13
4820185420051
Accessories inside the box
Battery charger, N-to-UHF adapter, NiMH rechargeable batteries (3 pcs), RigExpert AA-1400, Soft case with straps, USB cable, User’s manual
Note
Specifications are subject to change without notice, Мade in Ukraine
Frequency range
0.1 to 1000 MHz
Frequency entry
1 kHz resolution
SWR measurement range
1 to 10 in graph mode, 1 to 100 in numerical modes
R and X range
0…1000, -1000…1000 in graph mode, 0…10000, -10000…10000 in numerical modes
Display modes
R, X graph, 80 points, Smith (or polar) chart, 80 points, SWR at single or multiple frequencies, SWR graph, 80 points, SWR, return loss, R, X, Z, L, C at single frequency, TDR (Time Domain Reflectometer) graph
RF output
Connector type: N, Output power: -10 dBm (at a load of 50 ohms), Output signal shape: square, 0.1 to 200 MHz. For higher frequencies, harmonics of the main signal are used.
Power
Max. 3 hours of continuous measurement, max. 2 days in stand-by mode when fully charged batteries are used, Three 1.2V, 1800…3000 mAh, Ni-MH batteries, type AA, When the analyzer is connected to a PC or a DC adapter with USB socket, it takes power from these sources
Interface
320×240 color TFT display, 6x3 keys on the water-proof keypad, Multilingual menus and help screens, USB connection to a personal computer
Dimensions
230x100x55 mm (9x4x2”)
Operating temperature
0…40 °C (32…104 °F)
Weight
650g (23 Oz)
GTIN-13
4820185420044
Accessories inside the box
Battery charger, N-to-UHF adapter, NiMH rechargeable batteries (3 pcs), RigExpert AA-1000, Soft case with straps, USB cable, User’s manual
Note
Specifications are subject to change without notice, Мade in Ukraine
Frequency range
0.1 to 600 MHz
Frequency entry
1 kHz resolution
SWR measurement range
1 to 10 in graph mode, 1 to 100 in numerical modes
R and X range
0…1000, -1000…1000 in graph mode, 0…10000, -10000…10000 in numerical modes
Display modes
R, X graph, 80 points, Smith (or polar) chart, 80 points, SWR at single or multiple frequencies, SWR graph, 80 points, SWR, return loss, R, X, Z, L, C at single frequency, TDR (Time Domain Reflectometer) graph
RF output
Connector type: N, Output power: -10 dBm (at a load of 50 ohms), Output signal shape: square, 0.1 to 200 MHz. For higher frequencies, harmonics of the main signal are used.
Power
Max. 3 hours of continuous measurement, max. 2 days in stand-by mode when fully charged batteries are used, Three 1.2V, 1800…3000 mAh, Ni-MH batteries, type AA, When the analyzer is connected to a PC or a DC adapter with USB socket, it takes power from these sources
Interface
320×240 color TFT display, 6x3 keys on the water-proof keypad, Multilingual menus and help screens, USB connection to a personal computer
Dimensions
230x100x55 mm (9x4x2”)
Operating temperature
0…40 °C (32…104 °F)
Weight
650g (23 Oz)
Accessories inside the box
Battery charger, N-to-UHF adapter, NiMH rechargeable batteries (3 pcs), RigExpert AA-600, Soft case with straps, USB cable, User’s manual
GTIN-13
4820185420037
Note
Specifications are subject to change without notice, Мade in Ukraine
Frequency range
0.1 to 170 MHz
Frequency entry
1 kHz resolution
SWR measurement range
1 to 10
R and X range
0…10000, -10000…10000 in numerical modes, 0…200, -200…200 in graph mode
Display modes
R, X graph, 100 points, SWR at single or multiple frequencies, SWR graph, 100 points, SWR, return loss, R, X, Z, L, C at single frequency
RF output
Connector type: UHF (SO-239), Output power: -10 dBm (at a load of 50 ohms), Output signal shape: square, 0.1…30 MHz. For higher frequencies, third or fifth harmonics are used.
Power
Max. 3 hours of continuous measurement, max. 2 days in stand-by mode when fully charged batteries are used, Three 1.2V, 1800…2700 mA·h, Ni-MH batteries, type AA *, Three 1.5V alkaline batteries, type AA, When the analyzer is connected to a PC or a DC adapter with USB socket, it takes power from these sources
Interface
128×64 graphical backlit LCD, 6x3 keys on the water-proof keypad, Multilingual menus and help screens, USB connection to a personal computer
Dimensions
22·10·3.6 cm (9·4·1.5”)
Operating temperature
0…40 °C (32…104 °F)
Weight
400g (14 Oz)
Accessories inside the box
Alkaline batteries, CD with drivers and software, RigExpert AA-170, Soft case (optional, not included in standard package), Software manual, USB cable (optional, not included in standard package), User’s manual
GTIN-13
4820185420075
Note
* Ni-MH batteries are not included with the analyzer. Users can purchase these batteries with a corresponding charging adapter., Specifications are subject to change without notice, Мade in Ukraine
Frequency range
AA-54: 0.1 to 54 MHz
Frequency entry
1 kHz
SWR measurement range
1 to 10 in chart modes
R and X range
0…10000, -10000…10000 in numerical modes, 0…200, -200…200 in graph mode
Display modes
R, X graph, 100 points, SWR at single or multiple frequencies, SWR graph, 100 points, SWR, return loss, R, X, Z, L, C at single frequency
RF output
Connector type: UHF (SO-239), Output power: +13 dBm (at 50 Ohm load), Output signal shape: square, 0.1…10 MHz (AA-30) or 0.1…10.8 MHz (AA-54). For higher frequencies, third or fifth (AA-54) harmonics are used
Power
Max. 3 hours of continuous measurement, max. 2 days in stand-by mode when fully charged batteries are used, Two 1.2V, 1800…2700 mA·h, Ni-MH batteries, type AA *, Two 1.5V alkaline batteries, type AA, When the analyzer is connected to a PC or a DC adapter with USB socket, it takes power from these sources
Interface
128×64 graphical backlit LCD, 6x3 keys on the water-proof keypad, Multilingual menus and help screens, USB connection to a personal computer
Dimensions
22·10·3.6 cm (9·4·1.5”)
Operating temperature
0…40 °C (32…104 °F)
Weight
400g (14 Oz)
Accessories inside the box
Alkaline batteries, CD with drivers and software, RigExpert AA-54, Soft case (optional, not included in standard package), Software manual, USB cable (optional, not included in standard package), User’s manual
GTIN-13
4820185420013
Note
Specifications are subject to change without notice, Мade in Ukraine
Frequency range
AA-30: 0.1 to 30 MHz, AA-54: 0.1 to 54 MHz
Frequency entry
1 kHz
SWR measurement range
1 to 10 in chart modes
R and X range
0…10000, -10000…10000 in numerical modes, 0…200, -200…200 in graph mode
Display modes
R, X graph, 100 points, SWR at single or multiple frequencies, SWR graph, 100 points, SWR, return loss, R, X, Z, L, C at single frequency
RF output
Connector type: UHF (SO-239), Output power: +13 dBm (at 50 Ohm load), Output signal shape: square, 0.1…10 MHz (AA-30) or 0.1…10.8 MHz (AA-54). For higher frequencies, third or fifth (AA-54) harmonics are used
Power
Max. 3 hours of continuous measurement, max. 2 days in stand-by mode when fully charged batteries are used, Two 1.2V, 1800…2700 mA·h, Ni-MH batteries, type AA *, Two 1.5V alkaline batteries, type AA, When the analyzer is connected to a PC or a DC adapter with USB socket, it takes power from these sources
Interface
128×64 graphical backlit LCD, 6x3 keys on the water-proof keypad, AA-54: multilingual menus and help screens, AA-30:menus and help screens in English language, USB connection to a personal computer
Dimensions
22·10·3.6 cm (9·4·1.5”)
Operating temperature
0…40 °C (32…104 °F)
Weight
400g (14 Oz)
Accessories inside the box
Alkaline batteries, CD with drivers and software, RigExpert AA-30, Soft case (optional, not included in standard package), Software manual, USB cable (optional, not included in standard package), User’s manual
GTIN-13
4820185420020
Note
Specifications are subject to change without notice, Мade in Ukraine
Frequency range
0.1 to 230 MHz
Frequency entry
1 kHz
Measurement for systems
25, 50, 75, 100 Ohm
SWR measurement range
1 to 10 in chart modes, 1 to 100 in numerical modes
R and X range
0…1000, -1000…1000 in chart modes, 0…10000, -10000…10000 in numerical modes
Display modes
Cable tools (loss and characteristic impedance), R, X chart, 20 to 500 points, Return loss chart, 20 to 500 points, Smith chart, 20 to 500 points, SWR at single or multiple frequencies, SWR chart, 20 to 500 points, SWR, return loss, R, X, Z, L, C at single frequency, TDR (distance to fault)
RF output
Connector type: N, Output power: -10 dBm (at a load of 50 ohms), Output signal shape: square
Power
Four 1.2V Ni-MH batteries, type AAA, Four 1.5V alkaline batteries, type AAA, Max. 4 hours of continuous measurement, max. 2 days in standby mode when fully charged batteries are used, When the analyzer is connected to a PC or a DC adapter with USB socket, it takes power from these sources
Interface
290×220 color TFT display, 6x3 keys on the water-proof keypad, USB connection to a personal computer
Dimensions
82 x 182 x 32 mm (3.2 x 7.2 x 1.3 in)
Operating temperature
0…40 °C (32…104 °F)
Weight
236 g (8.32 oz)
Accessories inside the box
Alkaline batteries, N Male SO-239 Female adaptor, RigExpert AA-230 ZOOM Option BLE, Soft case, USB cable, User’s manual
GTIN-13
4820185420211
Note
Specifications are subject to change without notice, Мade in Ukraine
General features
CAT (Computer Aided Transceiver) system, CW keyer (WinKey), PTT and CW outputs, Transceiver audio interface for operating digital modes
Computer connection
No external power supply needed, Powered from the USB port (consuming 100 mA maximum), USB (Universal Serial Bus) connector
Transceiver connection
Single 25-pin connector for transceiver cable, Various transceiver models supported
Audio interface
Input/output samplerate: 8 to 48 kHz, Insulated from digital nets, Maximum input/output amplitude is 1V, True 16-bit DAC/ADC used, Volume levels are adjusted by the front panel potentiometers
CAT serial port
Baudrate: 300-115200 baud, Electrical compatibility: RS-232, CI-V, TTL or inverted-TTL (Yaesu, Icom, Kenwood, Ten-Tec, Elecraft and JRC transceivers)
PTT/CW outputs
CW output: open collector, Maximum current is 50 mA, PTT output: open collector and TTL-level
System requirements
Desktop or laptop computer with USB 1/2/3 compliant port, MacOS/Linux/Windows 2000/XP/2003/Vista/7/8/10 (32- or 64-bit) operating system, No drivers required for systems on Windows 10/MacOS/Linux
Supported software
all other soundcard software!, MixW 2/3/4, MMTTY, MMSSTV, WSJT, WSJT-X, WSPR
Dimensions
145 x 110 x 40 mm
Weight
200 g
Operating temperature
0…40 °C (32…104 °F)
GTIN-13
4820185420273
Note
Specifications are subject to change without notice, Мade in Ukraine
General features
CAT (Computer Aided Transceiver) system, FSK output, PTT and CW outputs, RS-485 port to connect external devices, such as antenna relays, Transceiver audio interface for operating digital modes, voice recording and playback
Transceiver connection
Single 25-pin connector for transceiver cable, Various transceiver models supported
Audio interface
Input/output samplerate: 8 to 48 kHz, Insulated from digital nets, Maximum input/output amplitude is 1V, True 16-bit DAC/ADC used
CAT serial port
Baudrate: 300-115200 baud, Electrical compatibility: RS-232, CI-V, TTL or inverted-TTL (Yaesu, Icom, Kenwood, Ten-Tec, Elecraft and JRC transceivers)
PTT/CW outputs
CW output: open collector, Maximum current is 50 mA, PTT output: open collector and TTL-level
FSK output
Baudrate: 45-1200 baud, Open collector output
Weight
300 g
Note
Мade in Ukraine
General features
CAT (Computer Aided Transceiver) system, CW keyer (WinKey), FSK output, PTT and CW outputs, Squelch input, Transceiver audio interface for operating digital modes, voice recording and playback
Computer connection
No external power supply needed, Powered from the USB port (consuming 100 mA maximum), USB (Universal Serial Bus) connector
Transceiver connection
Single 25-pin connector for transceiver cable, Various transceiver models supported
Audio interface
Input/output samplerate: 8 to 48 kHz, Insulated from digital nets, Maximum input/output amplitude is 1V, True 16-bit DAC/ADC used, Volume levels are adjusted by the front panel potentiometers
CAT serial port
Baudrate: 300-115200 baud, Electrical compatibility: RS-232, CI-V, TTL or inverted-TTL (Yaesu, Icom, Kenwood, Ten-Tec, Elecraft and JRC transceivers)
PTT/CW outputs
CW output: open collector, Maximum current is 50 mA, PTT output: open collector and TTL-level
System requirements
Desktop or laptop computer with USB 1/2/3 compliant port, No USB drivers required, Windows 2000/XP/2003/Vista/7/8/10 (32- or 64-bit) operating system
Weight
300 g
Operating temperature
0…40 °C (32…104 °F)
Note
Specifications are subject to change without notice, Мade in Ukraine
General features
CAT (Computer Aided Transceiver) system, FSK output, PTT and CW outputs, Squelch input, Transceiver audio interface for operating digital modes, voice recording and playback
Computer connection
No external power supply needed, Powered from the USB port (consuming 100 mA maximum), USB (Universal Serial Bus) connector
Transceiver connection
Single 25-pin connector for transceiver cable, Various transceiver models supported
Audio interface
Input/output samplerate: 8 to 48 kHz, Insulated from digital nets, Maximum input/output amplitude is 1V, True 16-bit DAC/ADC used, Volume levels are adjusted by the front panel potentiometers
CAT serial port
Baudrate: 300-115200 baud, Electrical compatibility: RS-232, CI-V, TTL or inverted-TTL (Yaesu, Icom, Kenwood, Ten-Tec, Elecraft and JRC transceivers)
PTT/CW outputs
CW output: open collector, Maximum current is 50 mA, PTT output: open collector and TTL-level
System requirements
Desktop or laptop computer with USB 1/2/3 compliant port, No USB drivers required, Windows 2000/XP/2003/Vista/7/8/10 (32- or 64-bit) operating system
Dimensions
11 x 13 x 4 cm
Weight
300 g
Operating temperature
0…40 °C (32…104 °F)
Note
Specifications are subject to change without notice, Мade in Ukraine
Frequency range
0.06 to 30 MHz
Frequency entry
1 Hz
Measurement for systems
25, 50, 75, 100 Ohm
Housing
none, PCB only – available as a kit
Display
4 LEDs
Communication interface
UART, 38400 baud
SWR measurement range
1 to 100
R and X range
0… 10000, -10000… 10000
RF output
Connector type: SMA, Output power: +13 dBm (at 50 Ohm load), Output signal shape: square, 0.06 to 30 MHz
Power
Current consumption (max) 150 mA, Supply: external 5V
General data
Dimensions (W x H x D), PCB only w/o connectors: 55 mm x 69 mm x 5 mm (2.1 in x 2.7 in x 0.2 in), Operating temperature: 0…40 °C (32…104 °F), Weight w/o connectors: 65 g (2.29 Oz)
Note
Specifications are subject to change without notice, Мade in Ukraine
GTIN-13
4820185420112
Antenna type
Slot Antenna Array
Frequency range
5725 MHz to 5875 MHz
Connector type
SMA (female)
Impedance
50 Ohm
Maximum power
250 W
Gain
15 dBi
Polarization
Linear (Vertical)
Radiation pattern
H-Plane 90°, V-Plane 8°
Mounting
1/4” Screw
Dimensions
40mm x 25mm x 450mm
Weight
400g (14 Oz)
GTIN-13
4820185420389
Застосування
Бренд
Застосування
Застосування
Бренд
Output voltage
13.8V (12-15V Software adjustable)
Rated power
600W
Rated current
40A
Input voltage range
80V to 264V
Input frequency range
47 Hz to 63 Hz
Acoustic noise
~21 dB
Overvoltage protection
Yes
Overcurrent protection
Yes
Short circuit protection
Yes
EMI noise
200mVp-p
Storage temperature range
-40°C to +85°C, -40°F to +185°F
Energy Conversion Efficiency (ECE)
> 90% (Heat dissipation at maximum load < 60 W)
Ports on the front panel
2 x 3A USB A Charging Ports, 2 x 3A USB Type-C Charging Ports, 2 x 45A Anderson Power Poles
Ports on the rear panel
1 x 30A Binding Post, 1 x USB Type-C for PC Communication, 2 х 45A Anderson Power Pole
Dimensions
172 mm x 55 mm x 185 mm
Weight
1,1 kg
Rated power
500W
Rated current
36A
Output voltage
13,8 V
Input voltage range
80V to 264V
Input frequency range
47 Hz to 63 Hz
Working temperature range
-30°C to +70°C
Acoustic noise
~21 dB
Overvoltage protection
Yes
Overcurrent protection
Yes
Short circuit protection
Yes
AC current
5,8 А @ 110 VAC | 2,9 А @ 230 VAC
EMC Emission
Class I: Class B, Class II: Class A
EMI noise
200mVp-p
Storage temperature range
-40°C to +85°C, -40°F to +185°F
Energy Conversion Efficiency (ECE)
> 90% (Heat dissipation at maximum load < 60 W)
Ports on the front panel
2 x 3A USB A Charging Ports, 2 x 3A USB Type-C Charging Ports, 2 x 45A Anderson Power Poles
Ports on the rear panel
1 x 30A Binding Post, 1 x 45A Anderson Power Pole, 1 x USB Type-C for PC Communication
Dimensions
172 mm x 55 mm x 185 mm
Weight
1,1 kg
Rated capacity
4950mAh, 36.6Wh
Nominal output voltage
7.4V
Chemistry
Li-ion LG INR21700M50LT
Charging protocol
BCP1.2, QC2.0
Charging port
USB Type-C
Nominal charge current
2A
Maximum charge current
3.0A
Nominal discharge current
1.5A
Discharge current protection
9.25A
Operating temperature
-20°C to +60°C
Charge temperature range
0°C to +45°C
Weight
206g (7,3Oz)
Expected Cycle Life
500 cycles ≥ 80% (@+25°C and nominal charge/discharge conditions)
